Description
Replacement spindle assembly for Exmark part number 103-8075 Complete Cutter Housing (ASM, CUTTER HSG COMPLETE). Now also replaces old part number 103-3200.
It fits some, but not all, Exmark models, including Lazer Z, Lazer Z EFI, Turf Ranger, and Turf Tracer – See the model fitment table below for more info.
This assembly may be the outside spindles only on some models – please reference a diagram for your specific Exmark’s model and serial number to verify usage and fitment.
| Model # | Serial # Range |
| LZ20KC524 | 370000 – 439999 |
| LZ20KC524AS | 440000 – 509999 |
| LZ23KC524AS | 510000 – 599999 |
| LZ23KC604 | 370000 – 439999 |
| LZ23KC604 | 440000 – 509999 |
| LZ23KC604 | 510000 – 599999 |
| LZ23KC604AS | 440000 – 509999 |
| LZ25KC524 | 510000 – 599999 |
| LZ25KC604 | 510000 – 599999 |
| LZ25KC604AS | 510000 – 599999 |
| LZ26KC604 | 370000 – 439999 |
| LZ26KC724 | 370000 – 439999 |
| LZ27DD604 | 320000 – 369999 |
| LZ27DD604 | 370000 – 439999 |
| LZ27DD604 | 440000 – 509999 |
| LZ27DD604 | 510000 – 599999 |
| LZ27DD724 | 320000 – 369999 |
| LZ27DD724 | 370000 – 439999 |
| LZ27DD724 | 440000 – 509999 |
| LZ27DD724 | 510000 – 599999 |
| LZ27KC524 | 370000 – 439999 |
| LZ27KC524 | 440000 – 509999 |
| LZ27KC524 | 510000 – 599999 |
| LZ27KC604 | 370000 – 439999 |
| LZ27KC604 | 440000 – 509999 |
| LZ27KC604 | 510000 – 599999 |
| LZ27KC724 | 370000 – 439999 |
| LZ27KC724 | 440000 – 509999 |
| LZ27KC724 | 510000 – 599999 |
| LZ27LKA604 | 370000 – 439999 |
| LZ27LKA604 | 440000 – 509999 |
| LZ27LKA604 | 510000 – 539999 |
| LZ27LKA724 | 370000 – 439999 |
| LZ27LKA724 | 440000 – 509999 |
| LZ27LKA724 | 510000 – 599999 |
| LZ28KC604 | 370000 – 439999 |
| LZ28KC604 | 440000 – 509999 |
| LZ28KC604 | 510000 – 599999 |
| LZ28KC724 | 370000 – 439999 |
| LZ28KC724 | 440000 – 509999 |
| LZ28KC724 | 510000 – 599999 |
| LZ31BV604 | 440000 – 509999 |
| LZ31BV604 | 510000 – 599999 |
| LZ31BV604 | 540000 – 599999 |
| LZ31BV724 | 440000 – 509999 |
| LZ31BV724 | 510000 – 599999 |
| LZ31BV724 | 540000 – 599999 |
| LZ31DG604 | 320000 – 369999 |
| LZ31DG604 | 370000 – 439999 |
| LZ31DG724 | 320000 – 369999 |
| LZ31DG724 | 370000 – 439999 |
| TR23KC | 370000 – 439999 |
| TR23KC | 440000 – 509999 |
| TR23KC | 510000 – 599999 |
| TT20KC | 440000 – 509999 |
| TT20KCC | 370000 – 439999 |
| TT20KCC | 440000 – 509999 |
| TT20KCC | 510000 – 539999 |
| TT23KAC | 370000 – 439999 |
| TT23KAC | 440000 – 509999 |
| TT23KAC | 510000 – 599999 |
| TT23KCC | 370000 – 439999 |
| TT23KCC | 440000 – 509999 |
| TT23KCC | 510000 – 539999 |
Replaces Exmark OEM Part Number:
- 103-8075
- 103-3200
Dimensions:
- Height: 6-1/2″
- Pulley OD: 5-1/2:
- Blade Bolt Specs: 5/8″-18×1-3/8″
Have a question about this product? Contact us for assistance and tell us you are looking at SKU 10872.
